Intel Dual Core 1200 MHz IOP348 I/O processor for RAID core and SAS microcode ,Default 512MB Up to 4GB DDR2-533 ECC SDRAM Cache,Intel RAID 6 engine to support extreme performance RAID 6 ,RAID level 0, 1, 10, 3, 5, 6, 30, 50, 60 or JBOD ,Multiple RAID selection ,Online Array roaming ,Online RAID level/stripe size migration ,Online volume set growth
Intel Dual Core 1200 MHz IOP348 I/O processor for RAID core and SAS microcode |
|
Default 512MB Up to 4GB DDR2-533 ECC SDRAM Cache |
|
Intel RAID 6 engine to support extreme performance RAID 6 |
|
RAID level 0, 1, 10, 3, 5, 6, 30, 50, 60 or JBOD |
|
Multiple RAID selection |
|
Online Array roaming |
|
Online RAID level/stripe size migration |
|
Online capacity expansion and RAID level migration simultaneously |
|
Online volume set growth |
|
Instant availability and background initialization |
|
Automatic drive insertion / removal detection and rebuilding |
|
Greater than 2TB per volume set (64-bit LBA support) |
|
Disk scrubbing/ array verify scheduling for automatic repair of all configured RAID sets |
|
Login record in the event log with IP address and service (http, telnet and serial) |
|
Support spin down drives when not in use to extend service life (MAID) |
|
Support NTP protocol to synchronize RAID controller clock over the on-board Ethernet port |
|
Max 128 LUNs (volume set) per controller |
|
Battery Backup Module ready (Option) |
Model Name |
EW-380AR-1680ix-24 |
Host Interface |
PCI-Express x8 Host Card |
Drive Interface |
24 SAS/SATAII drives |
Expansion Port |
1 x (4x3Gbps)miniSAS for expansion up to 122 devices |
Expansion Slot |
3*PCI-e 8x(8 Lane) slots and 4*PCI-e 4x(4 Lane) slots |
On Board Cache |
Default 512MB Up to 4GB DDR2-667 ECC SDRAM |
Power Supply |
2+1 Redundant 650W Power Supply |
Dimension |
4U 24Bays:559(D) x 482(W) x 176(H) mm |
Cooling |
Internal Three - 90x90x25 mm Fans & Rear Two - 60x60x25 mm Fans |
Weight |
4U 24Bays:30KG |
